Overview
The HP 25LL Litter-Lime Spreader provides rugged versatility for spreading multiple materials efficiently.
Precise
CHAIN WARRANTY DETAILS
For more information or to purchase the Pik Rite HP 25LL Litter-Lime Spreader, please contact Pik Rite’s team at 800-326-9763 or sales@pikrite.com
Precise
- Engineered spinners effectively distribute materials
- Adjustable gate
- Variable chain speed
- Optional scale system
- Side wind jack w/ safety chain
- Robust pintle chain with stainless steel pins
- Limited lifetime chain warranty
- Spring loaded take-up bearings allow for chain flex without damage
- All bearings have easy access grease fitting banks
- Sloped sides allow for easier loading
CHAIN WARRANTY DETAILS
For more information or to purchase the Pik Rite HP 25LL Litter-Lime Spreader, please contact Pik Rite’s team at 800-326-9763 or sales@pikrite.com
Specifications
| Struck Level ASAE S324.1 | 707 cu. ft. |
| Heaped SAE S324.1 | 1,058 cu. ft. |
| Load carrying capacity | 24.5 tons |
| Depth of box, inside | 55″ |
| Width of box, inside | 48″ / 96″ |
| Length of box, inside | 26′ 3″ |
| Overall width w/ flotation tires | 11’ 3” (710/50-26.5 |
| Overall height | 9’ 7″ |
| Overall length | 34’ 10″ |
| Loading height | 9′ 1″ |
| Beater speed | 420 RPM |
| Number of beaters | 2 |
| Paddles per beater | 6 |
| Fan diameter | 35.5″ |
| Tractor PTO HP (min.) | 200 HP |
| Unloading speeds | Infinite from 0-19’/min. |
| PTO speed | 1000 |
| PTO shaft diameter | 1 3/4″ |
| Endgate cylinders | 2 |
| Tare weight | 19,700 lbs. |
